Overview

Calibrie Logo

Calibrie is a modular Python library for the analysis, unmixing, and calibration of fluorescence flow cytometry data, particularly tailored for synthetic biology applications.

It implements multiple algorithms to turn raw fluorescence measurements into standardized, quantitative protein abundance units (like Molecules of Equivalent Fluorophore - MEF), along with numerous diagnostics and quality assessment tools. Calibrie is designed to promote reproducible, modular, and sharable cytometry analysis workflows.

Alpha Stage

Calibrie is currently in alpha. While functional, the API might undergo changes, and documentation is actively being developed. Feedback and contributions are welcome!

Core Philosophy

Calibrie is built on a few key principles inspired by the need for robust characterization in synthetic biology:

  • Modularity: Analysis steps are broken down into independent Task classes (like LoadControls, LinearCompensation, MEFCalibration). This allows flexible construction of analysis Pipelines tailored to specific experimental needs.
  • Reproducibility: By standardizing units (MEF-equivalents based on bead standards and protein mapping) and using explicit configuration files (YAML), Calibrie aims to make analyses repeatable across different datasets and even different labs (with caveats about instrument differences).
  • Transparency: The Context object explicitly tracks the flow of data between Tasks. Extensive diagnostics methods within tasks allow visualization of intermediate steps and final results, aiding in quality control and debugging.
  • Flexibility: Pipelines can be defined either directly in Python code for maximum control or through declarative YAML configuration files (leveraging the dracon library) for easier sharing and modification without code changes.

Installation

Calibrie is not yet on PyPI. To install it, clone the repository and install it locally:

git clone https://github.com/jdisset/calibrie.git
cd calibrie
pip install .
# Or for development:
# pip install -e .
Make sure you have the necessary dependencies installed (see pyproject.toml). You might need to install JAX separately depending on your hardware (CPU/GPU/TPU): JAX Installation Guide.

Quick Start

Here's a minimal example of defining and running a pipeline in Python:

import calibrie as cal
import pandas as pd

# Define controls and bead file paths (replace with actual paths)
controls_dict = {
    'EBFP2': 'path/to/ebfp2_control.fcs',
    'MNEONGREEN': 'path/to/mneongreen_control.fcs',
    'ALL': 'path/to/all_control.fcs',
    'BLANK': 'path/to/blank_control.fcs'
}
beads_file = 'path/to/beads.fcs'

# Example minimal pipeline (adjust parameters as needed)
pipeline = cal.Pipeline(
    tasks={
        "controls": cal.LoadControls(
            color_controls=controls_dict,
            use_channels=['PACIFIC_BLUE_A', 'FITC_A'] # Example
        ),
        "lincomp": cal.LinearCompensation(),
        # Add ProteinMapping and MEFCalibration for full calibration
    }
)

# Initialize (e.g., load controls, compute spillover)
# In a real scenario, LoadControls needs file paths.
# Here we assume they are set correctly inside the task definition.
pipeline.initialize()

# Load sample data
sample_data = cal.load_to_df("path/to/sample.fcs") # Use Calibrie's loader

# Apply pipeline
result_context = pipeline.apply_all(sample_data)
# Get unmixed arbitrary units
unmixed_abundances = result_context.abundances_AU

print(unmixed_abundances.head())

# Generate diagnostics (optional)
# figs = pipeline.all_diagnostics()
# if figs:
#   figs[0].fig.savefig("lincomp_diagnostics.png") # Save diagnostic figures

Explore the documentation to learn more about:
